Vertical Composite Compound Crusher Rock crusher rock Hammer mill for Gold Grinding
| Place of Origin | China |
|---|---|
| Brand Name | ASCEND |
| Certification | CE/ISSO9001 |
| Model Number | different models |
| Document | Product Brochure PDF |
| Minimum Order Quantity | 1 set |
| Price | USD 3500-35000 Per set |
| Packaging Details | Water and rust proof in wooden box or cotainer |
| Delivery Time | 10 days |
| Payment Terms | L/C, T/T, Western Union, MoneyGram |
| Supply Ability | 10 set per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Keyword | Fine Stone Crusher | Name | Compound Crusher |
|---|---|---|---|
| Motor Type | AC Motor | Dimension(L*W*H) | Different Size |
| Warranty | 1 Year | The Machines Classification | Stone Crushing Machine |
| Capacity | According Requirements |
Product Description
Product Description
Product Description
Compound crusher is suitable for crushing limestone, clinker, coal,iron ore, sand stone, gypsum, blast furnace residue, coal stone, piece coal, and other ores in building material, mine, metallurgy and chemical industry, and the compression strength of the materials to be crushed should not exceed 140MPa and the humidity should not be higher than 15%.
Working Principle
Working Principle
Materials fall into the high-speed rotation impeller from the above of machine, under the action of high-speed centrifugal force, have high-speed impact with another umbrella form materials which flow around the impeller, after they attack each other, then discharged from the bottom, it forms close-circuit and with many times circulation, it can achieve the required product size by screening equipment controlling.
Product pictures
Product Advantages
1. Big crushing ratio, grain-size can be adjusted arbitrarily;
2. Do not suffer plate hammer, lining board wear the impact;
3. No screen bar settings, crushing high water content, hydraulic large material clogging;
4. Using elastic and adjusting mechanism, not into broken material can self-control;
5. Won't cause harm equipment, bearing level decoration; crusher backing compound
6. Long service life, low comsumption ,stable running ,simple structure.
Specifications
Techinical parameters
| Model | PFL-800 | PFL-1000 | PFL-1250 | PFL-1500 | PFL-1750 |
| Feed Grain(mm) | 100 | 120 | 150 | 180 | 200 |
| Material-in Size (mm) | 0-5 | 0-5 | 0-5 | 0-5 | 0-5 |
| Trening Capacity(t/h) | 10-20 | 20-40 | 40-70 | 70-100 | 130-190 |
| Motor Power (kw) | 22 | 45-55 | 75 | 90-110 | 132-160 |
| Maine Shaft Speed(r/min) | 934 | 769 | 530 | 495 | 424 |
| Overall Dimension(mm) | 2100*1200*1700 | 2600*1400*1900 | 2800*1600*2100 | 3100*1900*2200 | 3710*2360*2390 |
| Weight(t) | 2.3 | 4.5 | 6.2 | 8.3 | 12 |
