Stone Powder Making Mining Crusher Machine

  • Stone Powder Making Mining Crusher Machine
  • Stone Powder Making Mining Crusher Machine
  • Stone Powder Making Mining Crusher Machine
  • Stone Powder Making Mining Crusher Machine
  • Stone Powder Making Mining Crusher Machine
Place of Origin China
Brand Name Ascend
Certification CE
Model Number PC400x300 PC600x400 PC800x600
Minimum Order Quantity 1 set
Price USD 3500-6000 Per set
Packaging Details wooden box and container
Delivery Time 10 working days
Payment Terms T/T, Western Union
Supply Ability 20 set per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Hammer Crusher Application Stone Crushing And Sand Making
Hammer Material Mn13Cr2 Color Customized
Warranty One Year Motor Type AC Motor
Application Mining,Quarry,Stone Warranty 1 Year
High Light

Stone Powder double roll crusher

,

Stone Powder Mining Crusher Machine
Leave a Message
Product Description

stone hammer crusher mill machine

The hammer crusher machine is suitable for crushing medium-hardness materials such as limestone, slag, coke, coal and so on in cement, chemical, electric power, metallurgy and other industrial departments. It has the advantages of simple structure, large crushing ratio and high production efficiency, which can break both dry and wet forms., Hammer Crusher can adjust grate strip gap according to user's requirement,Change the size of the material, This can meet the different needs of different users.

Stone Powder Making Mining Crusher Machine 0

Working priciple

In the hammer crusher mill machine,the motor drives the rotor to rotate at a high speed through the belt,and on the rotor there are series of hammers.when the material get into the working area of hammers,the rotating hammers with high rotation speed are crushing the material,the crushed product meeting the required size can be discharged by the outlet and become the final prodcuts,the large size prdocut are brought back to the crushing area by the hammers for being re-crushed until they reached the required size.

Stone Powder Making Mining Crusher Machine 1

Product advantages

1. Inlet large, high crushing chamber adapted material hardness, block degree, the product

powder less

2. Materials vacant, broken power consumption

3. New hammer, impact force

4. Hammer shaft mounted adjustable, hammer, long life

5. Grid size is adjustable, controllable particle size, particle shape is good

6. Chassis can be flipped, maintenance more convenient

7. Square shank bolts, impact resistance, wear and tear

8. Compact, machine rigidity

9. Fight structure, handling, easy to install

10. The machine shocks, counter, strike (rock stone) fragmentation functions in a high production efficiency, mechanical abrasion is small, the overall efficiency significantly, widely used in artificial sand

Stone Powder Making Mining Crusher Machine 2

Stone Powder Making Mining Crusher Machine 3

Hammer crusher parts

Stone Powder Making Mining Crusher Machine 4

Stone Powder Making Mining Crusher Machine 5

Hammer crusher specification

Model Rotor speed (r/min) Feed opening size (mm) Max feeding size (mm) Discharghing size (mm) Capacity (t/h) Motor power (kw) Weight (t) Overall dimensions L×W×H (mm)
PC300 × 200 1500 100*200 80 0-10 2-5 5.5 0.5 700 × 750 × 800
PC400×300 1500 145×295 100 0-30 5-8 7.5 0.9 844×942×878
PC600×400 1000 295×450 100 0-35 10-12 18.5 1.5 1000×1000×1300
PC600×600 1000 295×570 100 0-35 12-18 45 2.14 1315×840×1501
PC800×600 1000 350×570 120 0-45 20-25 55 2.45 1515×2586×1040
PC800×800 1000 350×850 120 0-45 35-45 55 3.05 1515×2831×1040
PC1000×800 1000 580×580 200 0-45 25-40 110 6.5 3206×2210×1515
PC1000×1000 1000 580×1060 200 0-45 40-80 132 7.59 3514×2230×1515
PC 1250×800 750 650×850 200 0-45 20-50 132 11.7 2630×1780×2050
PC1250×1250 750 650×1330 200 0-45 90-110 185 13.2 2630×2180×2050
PC1400×1400 750 1050×1540 250 0-45 120-170 280 17.2 2790×2800×2310
PC1600×1600 600 1500×1785 350 0-60 220-280 450 22.8 3350×3120×2660



Hammer crusher in working site

Stone Powder Making Mining Crusher Machine 6

Stone Powder Making Mining Crusher Machine 7
