Glass Limestone Hammer Mill Crusher

Place of Origin China
Brand Name Ascend
Certification CE
Model Number PC400x300 PC600x400 PC800x600
Minimum Order Quantity 1 set
Price USD 3500-6000 Per set
Packaging Details wooden box and container
Delivery Time 10 working days
Payment Terms T/T, Western Union
Supply Ability 20 set per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Hammer Crusher Mill Usage Stone Crushing
Hammer Material Mn13Cr2 Power 5.5 To 55KW
Warranty One Year Motor Type AC Motor
Condition New After-sales Service Provided Engineers Available To Service Machinery Overseas
Spare Parts Supply Will Supply Any Time
High Light

Limestone hammer crusher mill

,

Limestone double roll crusher

,

Glass Hammer Mill Crusher

Leave a Message
Product Description

stone hammer crusher mill machine

Hammer crusher has several features such as big crushing ratio, high production capacity and uniform product size. Hammer crusher can crush the maximum size of 600-1800 mm materials into 25mm or below 25 mm size, so it is also known as crusher hammer or hammer mill crusher. Because it is often used for coal crushing in coal mines, it is also known as coal crusher.

Application Fields Of Hammer Crusher:

Hammer crusher is used for crushing all kinds of hard and abrasive materials with less than 100MPa compressive strength and less than 15% water content, such as coal, salt, chalk, gypsum, limestone, brick and tile. It also can be used to crush fiber structure, asbestos cement waste and asbestos fibers recycling.

Glass Limestone Hammer Mill Crusher 0

Working priciple

In the hammer crusher mill machine,the motor drives the rotor to rotate at a high speed through the belt,and on the rotor there are series of hammers.when the material get into the working area of hammers,the rotating hammers with high rotation speed are crushing the material,the crushed product meeting the required size can be discharged by the outlet and become the final prodcuts,the large size prdocut are brought back to the crushing area by the hammers for being re-crushed until they reached the required size.

Glass Limestone Hammer Mill Crusher 1

Product advantages

1. Inlet large, high crushing chamber adapted material hardness, block degree, the product

powder less

2. Materials vacant, broken power consumption

3. New hammer, impact force

4. Hammer shaft mounted adjustable, hammer, long life

5. Grid size is adjustable, controllable particle size, particle shape is good

6. Chassis can be flipped, maintenance more convenient

7. Square shank bolts, impact resistance, wear and tear

8. Compact, machine rigidity

9. Fight structure, handling, easy to install

10. The machine shocks, counter, strike (rock stone) fragmentation functions in a high production efficiency, mechanical abrasion is small, the overall efficiency significantly, widely used in artificial sand

Glass Limestone Hammer Mill Crusher 2

Glass Limestone Hammer Mill Crusher 3

Glass Limestone Hammer Mill Crusher 4

Hammer crusher parts

Glass Limestone Hammer Mill Crusher 5

Glass Limestone Hammer Mill Crusher 6

Hammer crusher specification

Model Rotor speed (r/min) Feed opening size (mm) Max feeding size (mm) Discharghing size (mm) Capacity (t/h) Motor power (kw) Weight (t) Overall dimensions L×W×H (mm)
PC300 × 200 1500 100*200 80 0-10 2-5 5.5 0.5 700 × 750 × 800
PC400×300 1500 145×295 100 0-30 5-8 7.5 0.9 844×942×878
PC600×400 1000 295×450 100 0-35 10-12 18.5 1.5 1000×1000×1300
PC600×600 1000 295×570 100 0-35 12-18 45 2.14 1315×840×1501
PC800×600 1000 350×570 120 0-45 20-25 55 2.45 1515×2586×1040
PC800×800 1000 350×850 120 0-45 35-45 55 3.05 1515×2831×1040
PC1000×800 1000 580×580 200 0-45 25-40 110 6.5 3206×2210×1515
PC1000×1000 1000 580×1060 200 0-45 40-80 132 7.59 3514×2230×1515
PC 1250×800 750 650×850 200 0-45 20-50 132 11.7 2630×1780×2050
PC1250×1250 750 650×1330 200 0-45 90-110 185 13.2 2630×2180×2050
PC1400×1400 750 1050×1540 250 0-45 120-170 280 17.2 2790×2800×2310
PC1600×1600 600 1500×1785 350 0-60 220-280 450 22.8 3350×3120×2660



Hammer crusher in working site

Glass Limestone Hammer Mill Crusher 7

Glass Limestone Hammer Mill Crusher 8
